PCIe SSD 115S

250gb M.2 Nvme

Appearance

Dimensions Single-sided: 80 mm x 22 mm x 2.23 mm (3.15″ x 0.87″ x 0.09″)

Weight: 8 g (0.28 oz)

Type: M.2 2280

Interface

Bus Interface: NVMe PCIe Gen3 x4

Storage

Flash Type: 3D NAND flash

Capacity: 250GB

Operating Environment

Operating Temperature: 0°C (32°F) ~ 70°C (158°F)

Operating Voltage: 3.3V±5%

Performance

Sequential Read/Write (CrystalDiskMark): 250 GBUp to 3,000/1,300 MB/s

4K Random Read/Write (IOmeter): 250 GBUp to 250,000/170,000 IOPS

Terabytes Written (TBW): 250 GB100 TBW

Mean Time Between Failures (MTBF): 2,000,000 hour(s)

Drive Writes Per Day (DWPD): 0.2 (5 yrs)

Note:
Speed may vary due to host hardware, software, usage, and storage capacity.
The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
Terabytes Written (TBW) expresses the endurance under the highest capacity.
Some motherboards only provide PCIe x2 connections for the M.2 slot, creating a bottleneck on even the fastest drives.

System Requirement

Operating System:
Microsoft Windows 7 or later
Linux Kernel 2.6.31 or later

Note:
Please make sure that your computer has a M.2 slot.
Systems for use with the PCIe M.2 SSD must have an M.2 connector with only an M key. B-key connectors are not compatible. Improper insertion may lead to damage. Please click here for more information.

Technology

S.M.A.R.T.:

Advanced Garbage Collection:

RAID Engine: –

LDPC Coding:

DRAM Cache: –
